D-WOOL CFBB 1000 Biosoluble Ceramic Fiber Blanket

D-WOOL CFBB 1000 Biosoluble Ceramic Fiber Blanket

D-WOOL CFBB 1000 Biosoluble is an MED-certified, high-temperature AES Ceramic Fiber Blanket manufactured at Ravago facilities with a strong commitment to human health, workplace safety, and environmental sustainability. Engineered with low bio-persistent fibers that dissolve safely in human body fluids, it eliminates bio-accumulation risks, offering maximum health safety for shipyard personnel, installers, and crew. Fully compliant with IMO FTP Code and SOLAS standards, it features an 1100°C classification and a 1000°C continuous rating, providing eco-friendly A60 fire protection across vessel interiors, engine rooms, and exhaust systems.

Key Features
  • MED (Wheelmark) Certified, Fully Compliant with SOLAS and IMO FTP Code
  • Advanced Biosoluble AES Fiber Technology (Low Bio-Persistence)
  • 1100°C Classification Temperature & 1000°C Continuous Thermal Rating
  • Certified A60 Fire Safety Standard with Zero Fume Generation
  • Double-Sided Needled Construction Resisting Engine Vibrations & Mechanical Shocks
  • Exceptional Flexibility for Easy Tailoring of Removable Jackets & Tight Space Fitting
  • Multiple Thicknesses from 13 mm to 50 mm & Widths of 610/1220 mm
  • Main Category: IMPA Section 81 – Thermal Insulation & Fire Protection Materials / Biosoluble Insulation
  • Related Catalogue Category: Biosoluble Insulation Blankets / Eco-Friendly High-Temp Products
  • Directly Matched IMPA References:
    • IMPA 811671: SHEET CERAMIC FIBER, 6×600×7200 mm (Biosoluble Alternative)
    • IMPA 811672: SHEET CERAMIC FIBER, 12.5×600×7200 mm (Biosoluble Alternative)
    • IMPA 811673: SHEET CERAMIC FIBER, 25×600×7200 mm (Biosoluble Alternative)
    • IMPA 811674: SHEET CERAMIC FIBER, 50×600×3600 mm (Biosoluble Alternative)
  • Related IMPA Description: Engineered beyond standard commodity classifications, the D-WOOL series represents an advanced marine thermal formulation produced by Ravago. Relevant IMPA catalog references are tailored and selected based on the specific insulation detail and operating temperature of your project.
  • Product Classification: Biosoluble Ceramic Fiber Blanket / AES High-Temperature Blanket
  • Product Type: MED approved, body-soluble high-temperature ceramic fiber blanket
  • Product Search Keywords: Biosoluble Blanket, AES Fiber Blanket, Eco Friendly Marine Insulation, IMO MED Biosoluble Wool, Low Biopersistence Blanket, A60 Fire Insulation, IMPA 811671, IMPA 811672, IMPA 811673, IMPA 811674, D-WOOL CFBB 1000
  • Brand & Product Code: DEHA MARINE — D-WOOL CFBB 1000 Biosoluble
  • Product Type: Biosoluble AES (Alkaline Earth Silicate) Ceramic Fiber Blanket (White)
  • Certification: MED (Wheelmark No: 0437/25) / IMO FTP Code & SOLAS Compliant (Module B & D)
  • Classification Temperature: 1100°C
  • Continuous Operating Temp: 1000°C
  • Linear Shrinkage: ≤3.0% (at 1000°C / 24 hrs)
  • Thermal Conductivity (at 400°C): 0.10 W/mK (96 kg/m³)
  • Density Options: 64,96,110,128,160 kg/m³
  • Thickness / Width: 13, 20, 25, 38, 50 mm / 610 mm and 1220 mm
  • Application Areas: Vessel interior linings, engine rooms, exhaust systems, A60 bulkheads, green shipping & luxury yacht projects
