D-Wool CFB1260

D-Wool CFB1260 Ceramic Fiber Blanket

D- WOOL CFB1260 Ceramic Fiber Blanket

D-WOOL CFB1260 is a MED certified ceramic fiber blanket designed for marine and industrial insulation. Fully compliant with IMO FTP Code and SOLAS standards, it provides thermal resistance up to 1260°C and A60 fire protection. With its lightweight, flexible, and easy-to-install structure, it is widely used in ship insulation, pipe and equipment coverings, boilers, and exhaust systems. Thanks to its high fire resistance and durability, D-WOOL CFB1260 stands out among marine insulation solutions, ensuring both safety and energy efficiency.

Application Areas:

D-Wool CFB1260 is a high-performance ceramic fiber blanket designed for thermal insulation in extreme temperatures. It provides excellent heat resistance and thermal stability, making it ideal for industrial applications such as furnaces, kilns, and boilers. Lightweight yet durable, it offers superior insulating properties and contributes to energy efficiency. This eco-friendly solution is also resistant to thermal shock, ensuring long-term reliability and performance.

Areas of Usage

Physical Properties

  • Furnace, kiln, reformer and boiler linings
  • Investment casting mold wrappings
  • Removable insulating blankets for stress relieving welds
  • Reusable insulation for steam and gas turbines
  • Flexible high-temperature pipe
  • Pressure and cryogenic vessel fire protection
  • High-temperature kiln, furnace, gasketing & filtration
  • Furnace door linings and furnace repairs
  • Soaking pit seals
  • Thermal reactor insulation
  • Expansion joint seals
  • Primary reformer header insulation
  • Glass furnace crown insulation
  • Incineration equipment and stack linings
  • Annealing cover seals
  • Nuclear insulation applications
  • Atmosphere furnace lining
  • Field steam generator lining
  • Chemical process heaters
  • Colour: White
  • Classification Temperature (°C): 1260 °C
  • Usage Temperature (°C): 1200 °C
  • Linear Shrinkage After Heating (%): 1200 °C, 24 saat / < %3,0
  • Density (kg/m³): (Tolerance: -10% / +5%) 64 96 110 128 160
  • Thickness (mm): 13 mm (Tolerance: -1 / +10), 25 mm (Tolerance: -5 / +10), 38 mm (Tolerance: -8 / +10), 50 mm (Tolerance: -10 / +10)
  • Length (mm): (Tolerance: -10 / +10) 14400 mm, 7200 mm, 4730 mm, 3600 mm
  • Width (mm): (Tolerance: -5 / +10) 610 mm
  • Tensile Strength (MPa): 64 kg/m³: >0,03 Mpa, 96 kg/m³: > 0,05 Mpa, 110 kg/m³: > 0,055 Mpa,128 kg/m³: > 0,06 Mpa, 160 kg/m³: > 0,075 MPa

Storage and Shelf life

  • Product packages should be placed on at least one pallet which should not be in direct contact with the ground at storage area.
  • Product packages should be protected from water, moisture and sunlight in the storage area.
  • Appropriate work safety clothing and equipment must be used to protect the skin, eye and upper respiratory system during transport.
  • Products must be covered with a tarpaulin when
  • Do not leave any material on the products in such a way as to damage the package and the product.
  • Palletized products should not be stacked and stored on top of each other.
  • The opened packages must not be disposed of and must be disposed of in accordance with the regulations.
Density (kg/m³)Temp (°C)Thermal Conductivity (W/mK)Thermal Resistance (m²K/W)
644000.150.08–0.33
646000.180.07–0.27
648000.210.06–0.23
964000.110.11–0.45
966000.140.09–0.35
968000.170.07–0.29
1104000.100.13–0.50
1106000.130.10–0.38
1108000.160.08–0.31
1284000.0960.13–0.52
1286000.1230.11–0.41
1288000.1560.08–0.32
1604000.080.16–0.62
1606000.110.11–0.45
1608000.140.09–0.35
